Push the limits with the i-PRO WV-X86531-Z2. The combination of a 4 × 5 MP multi-directional camera and a 2 MP 21× PTZ, together with AI automatic tracking and IP67/IK10 durability, supports perimeter security.
The i-PRO WV-X86531-Z2 is an “all-in-one” security solution with a stylish black body that combines advanced multi-directional monitoring with a powerful PTZ mechanism. Its four fixed 5 MP high-resolution sensors provide uninterrupted 360-degree panoramic surveillance, while the integrated PTZ camera with 2 MP 21× optical zoom follows suspicious objects in the finest detail. The built-in Edge AI engine analyses the data from the fixed sensors and, when it detects a person or vehicle, automatically directs the PTZ unit towards it and starts smart tracking (Auto Tracking). IP66, IP67 and IK10 certification gives protection against all the harsh conditions of the outdoors and against impact. Delivering the performance of 5 different cameras over a single cable and a single IP address, this device has FIPS 140-2 Level 3 cybersecurity and is designed for areas that need wide coverage and simultaneous detailed inspection, such as city squares, large car parks and airports.
| Attribute | Value |
|---|---|
| Identification | |
| Series | X Series |
| Camera type | Dome |
| Environment | Outdoor |
| Mounting type | Ceiling, Wall, Pole |
| Signal type | IP network |
| Imaging | |
| Resolution | 5 MP |
| Maximum resolution | 2560 × 1920 |
| Sensor type | 4× 1/2.7″ CMOS, 1× 1/2.8″ CMOS |
| Backlight masking | Yes |
| Dynamic range | 108 dB |
| Compression type | H.265, H.264, JPEG |
| Wide dynamic range | Yes |
| Day/night | Yes |
| Automatic gain control | Yes |
| Automatic white balance | Yes |
| Backlight compensation | Yes |
| Digital noise reduction | Yes |
| Optics | |
| Lens type | Motorised |
| Lens size | 84.6 mm |
| Optical zoom | 21× |
| Digital zoom (optical included) | 336× |
| Illuminator type | None |
| Smart IR | No |
| Image analysis | |
| Face detection | Yes |
| Defog | Yes |
| Image flip | No |
| Motion detection | Yes |
| Privacy masking | Yes |
| Privacy zone | Yes |
| On-screen display menu | Yes |
| Network | |
| Network interface | 10BASE-T/100BASE-TX/1000BASE-T, RJ45 |
| Protocols | IPv4, IPv6, TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DHCPv6, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, FTP, SFTP, LLDP, MQTT |
| SD card | microSD, microSDHC, microSDXC |
| ONVIF | Yes |
| Power | |
| Power source | PoE++ IEEE802.3bt |
| Power consumption | 35.6 W |
| Environment and protection | |
| Protection type | IP66, IP67, IK10 |
| Protection standards | IEC 60529, IEC 62262, UL50E Type 4X, NEMA 4X |
| Housing | Die-cast aluminium body, Polycarbonate dome, Stainless steel external screws |
| Heater | No |
| Fan | No |
| Stand | No |
| Inputs and outputs | |
| Alarm input | Yes |
| Alarm output | Yes |
| Microphone input | Yes |
| Analogue video output | Yes |
| Physical | |
| Operating temperature (min) | −40 °C |
| Operating temperature (max) | 55 °C |
| Weight | 3.8 kg |
| Dimensions | Ø250 × H195 mm |
| Advanced | |
| Advanced functions | Edge AI analytics, AI auto tracking, Pan/Tilt speed 500 deg/s, FIPS 140-2 Level 3 SecureElement, NDAA compliant |
| Other features | 4× multi-directional + 1× PTZ |
